   1 # -*- coding: iso-8859-1 -*-
   2 """
   3 GraphViz parser module for MoinMoin
   4
   5 ----
   6 Copyright (C) 2007 Zoran Isailovski
   7 Copyright (C) 2008 Remco Boerma
   8 Licensed under the Apache License, Version 2.0 (see http://www.apache.org/licenses/LICENSE-2.0)
   9 or, at your option, under the terms described in the file LICENSE.txt found in the root of the
  10 distribution of this package (as far as it denotes a different license then the above).
  11 """
  12 import os.path
  13 import sha
  14 import re
  15 from MoinMoin.parser import text_moin_wiki
  16 from MoinMoin import wikiutil
  17 from MoinMoin.action import AttachFile
  18
  19 VALID_GRAPHVIZ_TOOLS = 'dot twopi neato circo fdp'.split()
  20
  21 def seek(cmd):
  22     """Returns the first valid path for cmd in $PATH or None."""
  23     for directory in os.environ['PATH'].split(os.pathsep):
  24         filepath = os.path.join(directory,cmd)
  25         if os.path.exists(filepath):
  26             return filepath
  27     return None
  28
  29 class Parser:
  30     """ MoinMoin graphViz parser."""
  31     extensions = []
  32     Dependencies = []
  33
  34     def __init__(self, raw, request, **kw):
  35         """ Validate and store arguments provided by Moin.
  36
  37         self.raw = raw text provided
  38         self.formatter = formatter provided by the user
  39         """
  40         # get the formatter from the 'commandline'
  41         self.formatter = kw.get('format_args','dot').strip()
  42         # validate if it's save...
  43         if self.formatter.lower() not in VALID_GRAPHVIZ_TOOLS:
  44             self.error_msg = "%r is not a valid formatter" % \
  45                              self.formatter
  46         # if we're on windows: add .exe to make things work
  47         if os.name == 'nt':
  48             self.formatter += ".exe"
  49         print `self.formatter`
  50         # set self.formatter to the path leading to the formatter
  51         self.formatter = seek(self.formatter)
  52         # provide an error if no file in $PATH could be found
  53         if self.formatter is None:
  54             self.error_msg = "Cannot find executable for %r" % \
  55                              self.formatter
  56         # store the raw and request for later processing
  57         self.raw = raw
  58         self.request = request
  59         # find the attachments directory for this page
  60         self.store_attachments_in = \
  61              request.formatter.page.getPagePath('attachments')
  62         # investigate whether a map file is required
  63         self.need_map = raw.find('URL') > -1
  64         # create a unique identifier within this page
  65         self.fingerprint = sha.new(raw).hexdigest()
  66         # calculate the png name
  67         self.png_filename = os.path.join(self.store_attachments_in,
  68                                  'diagram-'+self.fingerprint+'.png')
  69         # calculate the map name
  70         self.map_filename = os.path.join(self.store_attachments_in,
  71                                  'diagram-'+self.fingerprint+'.map')
  72
  73
  74     def generate_files(self):
  75         """Produce the png file (and optionally the map file)."""
  76         # check if the cached result is enough
  77         if os.path.exists(self.png_filename) and \
  78            (os.path.exists(self.map_filename) or not self.need_map):
  79             return
  80         # determine the commandline for generating the image
  81         cmdline = '%s -Tpng -Gbgcolor=transparent -o %s' % \
  82                     (self.formatter,self.png_filename)
  83         p = os.popen(cmdline, 'w')
  84         p.write(self.raw)
  85         p.close()
  86         if self.need_map:
  87             # if the map file is required create that one as well
  88             cdmline = '%s -Tcmap -o %s' % \
  89                       (self.formatter, self.map_filename)
  90             p = os.popen('dot -Tcmap -o ' + self.map_filename, 'w')
  91             p.write(self.raw)
  92             p.close()
  93
  94
  95     def format(self, formatter):
  96         if hasattr(self,'error_msg'):
  97             # handle stored errors by printing them
  98             # and returning immidiatly
  99             self.request.write(formatter.text(
 100                 wikiutil.escape(self.error_msg)))
 101             return
 102         self.generate_files()
 103         img_url = AttachFile.getAttachUrl(
 104                     formatter.page.page_name,
 105                     os.path.split(self.png_filename)[1],
 106                     self.request)
 107         if self.need_map:
 108             # write html to show the image and linked to a map
 109             self.request.write(
 110                 formatter.image(src = img_url,
 111                                 usemap = '#' + self.fingerprint,
 112                                 border = 0,
 113                                 ismap = True))
 114             # read map from disk
 115             p = open(self.map_filename, 'r')
 116             map_contents = p.read()
 117             p.close()
 118             # write the map html to the stream
 119             map_html = '<MAP name="'+ self.fingerprint + '">\n'+ \
 120                        map_contents + '</MAP>'
 121             self.request.write(formatter.rawHTML(map_html))
 122         else:
 123             # write a line to include the graphic
 124             self.request.write(formatter.image(src = img_url))
 125
 126
 127 ##class Snippets:
 128 ##    STD_GRAPH_HEADER = '''overlap=false
 129 ##    node [fontname=Verdana fontsize=10 style=filled fillcolor=azure color=steelblue fontcolor=steelblue]
 130 ##    edge [fontname=Verdana fontsize=8 color=steelblue fontcolor=steelblue]'''
 131 ##
 132 ##    ATTEMPT_TO_JOIN_EDGES = 'concentrate=true'
 133 ##    LEFT_TO_RIGHT = 'rankdir=LR'
